Netafim

TECHFLOW EMITTERS - Pressure Compensating Emitters

SKU: 21020-001315

$19.50
Title:
Quantity:

Pressure Compensating Drippers

PROVIDE UNIFORM FLOW DISTRIBUTION

Pressure Compensating Drippers (PC) developed with advanced pressure compensating technology delivers a uniform flow rate even in areas with difficult topographical conditions. A unique pressure differential mechanism regulates flow and provides self-cleaning action, even while irrigating – for a clog-resistant design and high emission uniformity.

Why Pressure Compensating Drippers?

PC DRIPPERS MAINTAIN A UNIFORM FLOW RATE WITH THE WIDEST COMPENSATION RANGE - 7 TO 58 psi

  • Higher and Better Quality Yields: 100% uniformity of water and nutrient delivery over a broad pressure range ensures uniform crop yields and bigger harvests.
  • Clogging Resistance: Continuous self-flushing technology ensure consistent flow-rates and flawless operation – even with harsh water.
  • Easy to Scale: Number of drippers can be easily increased ensuring sufficient water to meet your crop growth rate requirements.
  • Maximum Flexibility: Micro-tubes allow drippers to be positioned exactly where required, and split into several drip outlets if needed.
  • Anit-Drain Mechanism (CNL Feature): Eliminates drainage & refill effect, and improves efficiency during pulse irrigation.

Product Advantages

  • Patented pressure differential system maintains uniform flow rate at different inlet working pressures (within the recommended range) ensuring exact distribution of water and nutrients.
  • Industry’s widest flow path and wider dripper cross-section allow large particles through the dripper’s short flow path.
  • Continuous self-flushing system, even while irrigating, provides improved resistance to clogging.
  • Ideal for areas with difficult topographical conditions.

Applications

  • Vineyards
  • Orchards
  • Greenhouses and Nurseries

Specifications

  • PC and WPC Base Color and Flow (GPH):
    Red 0.53, Black 1.06 and Green 2.11
  • PC and WPC (Non-CNL): Recommended Operating Pressure: 7 - 58 psi
  • WPC (With CNL): Recommended Operating Pressure: 14.5 - 58 psi Shut-Off (Closing) Pressure: 2.17 psi (5' of Elevation)
  • Recommended Filtration: 120 Mesh
